Description
General InformationBrandRidgidApplicationPipe ThreadingPackagingRetailCountry of OriginUnited StatesUPC095691299284California ResidentsProposition 65 WarningPart Number29928Product TypeThreading MachineReturn PolicyNCNR – Non-Cancellable / Non-ReturnablePhysical CharacteristicsWeight114.76 kg253.00 lbColorRed, Silver & BlackMaterialCast Iron, Steel & PlasticDetailsFeaturesSpeed hammer-type chuck with rocker-action jaws secures pipe tightly
Large chip tray and 1.75 gallon oil tray allow for longer uninterrupted threading
Wide top cover provides space for keeping tools and fittings handy
High clearance carriage increases workpiece maneuverability to make threading easier
Suitable for use with geared threaders (Models 141 and 161, sold separately) for threading large diameter pipe
Length gauge ensures quick and accurate cut-off
Uses Model 816/817 semi-automatic, Model 815A self-opening, or Model 811A quick-opening die heads – Die head and dies all sold separatelySizePipe Capacity: 1/8″ to 2″ (3 mm to 50 mm); 2 1/2″ to 4″ (65 mm to 100 mm) with 141 Geared Threader; 4″ to 6″ (100 mm to 150 mm) with 161 Geared Threader
Bolt Capacity: 1/4″ to 2″ (6 mm to 50 mm)
Controls: Rotary Type Forward/Off/Reverse Switch; integral foot switch
Chuck: Speed chuck with replaceable rocker-action jaw inserts
Rear Centering Device: Cam-action, turns with chuck
Cutter: Model 820 Wheel-Type Cutter, self-centering, full-floating, 1/8″ to 2″
Reamer: Model 341, 5-flute cone, RH, 1/8″ to 2″
Oil Pump: Self-priming gerotor oil pump
Operating Speeds: 36 RPM
Motor: Universal, 1/2 HP, 230V, 7.55 Amps
